Fulvia carburettor support strap

The Solex (or Dell'Orto substitute) carburettors on a Lancia Fulvia with twin carburettors are attached at the inlet manifold by a rubber mount.    To prevent that mount splitting under the weight of the airbox and carburettors, a mount was attached to the underside of the airbox and triangulates the carburettors to a mounting on the block.

This support strap (arm / mount / rod - or whatever you want to call it) is awkward to attach and many Fulvias are missing this item.

There are two standard versions available.

A long version for cars without the factory-fit oil cooler [most cars]
or
A shorter version for Series 1 cars with the factory fitted oil cooler.

If you are running without the factory air cleaner housing, it is still sensible to have a brace between the carburettors and the block - we can assist with that as well if necessary.

Note: The long version is illustrated.   The shorter version looks virtually identical.

These are made in-house, so if they are not in stock, it will be made for you.
